fpmas::io::DistributedCsvOutput< DataFieldOperation > Class Template Reference

#include <csv_output.h>

Inheritance diagram for fpmas::io::DistributedCsvOutput< DataFieldOperation >:

Collaboration diagram for fpmas::io::DistributedCsvOutput< DataFieldOperation >:

Public Member Functions
	DistributedCsvOutput (api::communication::MpiCommunicator &comm, int root, api::io::OutputStream &output_stream, DistributedCsvField< DataFieldOperation >... csv_fields)
	DistributedCsvOutput (api::communication::MpiCommunicator &comm, api::io::OutputStream &output_stream, DistributedCsvField< DataFieldOperation >... csv_fields)
void	dump () override
Public Member Functions inherited from fpmas::io::OutputBase
	OutputBase (api::io::OutputStream &output_stream)
const api::scheduler::Job &	job () override
virtual void	dump ()=0
virtual const scheduler::Job &	job ()=0

Additional Inherited Members
Protected Member Functions inherited from fpmas::io::CsvOutputBase< DataFieldOperation::Type... >
void	dump_csv (const std::vector< std::string > &data)
std::vector< std::string >	headers ()
std::vector< std::string >	dump_fields ()
	CsvOutputBase (api::io::OutputStream &output_stream, std::pair< std::string, std::function< DataField()> >... csv_fields)
Protected Attributes inherited from fpmas::io::OutputBase
api::io::OutputStream &	output_stream

Detailed Description

template<typename... DataFieldOperation>
class fpmas::io::DistributedCsvOutput< DataFieldOperation >

A distributed api::output::Output implementation that dumps CSV data to an output stream.

Data is automatically gathered on all processes, and can be dumped on one processes or on all the processes.

Parameters

DataField

types of data in each row

Constructor & Destructor Documentation

DistributedCsvOutput() [1/2]

template<typename... DataFieldOperation>

fpmas::io::DistributedCsvOutput< DataFieldOperation >::DistributedCsvOutput ( api::communication::MpiCommunicator &  comm, int  root, api::io::OutputStream &  output_stream, DistributedCsvField< DataFieldOperation >...  csv_fields  )

inline

DistributedCsvOutput constructor.

When this version is used, specifying a root parameter, data is only dumped on output_stream on the process corresponding to root (according to the specified comm). On all other processes, output_stream is ignored.

Parameters

comm	MPI communicator
root	rank of the process on which data is dumped
output_stream	output stream on which data are dumped (ignored on processes other than root)
csv_fields	tuples of type {"field_name", watcher, params}, where watcher is a callable object used to fetch data corresponding to "field_name". params is optional. See examples for concrete use cases.

DistributedCsvOutput() [2/2]

template<typename... DataFieldOperation>

fpmas::io::DistributedCsvOutput< DataFieldOperation >::DistributedCsvOutput ( api::communication::MpiCommunicator &  comm, api::io::OutputStream &  output_stream, DistributedCsvField< DataFieldOperation >...  csv_fields  )

inline

DistributedCsvOutput constructor.

When this version is used, withou specifying a root parameter, data is dumped on output_stream on all the processes.

Parameters

comm	MPI communicator
output_stream	output stream on which data are dumped on each process
csv_fields	tuples of type {"field_name", watcher, params}, where watcher is a callable object used to fetch data corresponding to "field_name". params is optional. See examples for concrete use cases.

Member Function Documentation

dump()

template<typename... DataFieldOperation>

void fpmas::io::DistributedCsvOutput< DataFieldOperation >::dump ( )

inlineoverridevirtual

The dump process is implictly performed in several steps:

1. Fetch local data on each process
2. Gather data
3. Reduces gathered data
4. Serialize and dump CSV formatted data to output_stream

Depending on the constructor used, data is gathered and dumped only at root or on all the processes.

Implements fpmas::api::io::Output.

---

The documentation for this class was generated from the following file:

• src/fpmas/io/csv_output.h
